NXP i.MX8M Plus Quad Core Processor Based IIoT Gateway Platform
Features
• NXP Arm® Cortex®-A53 i.MX8M Plus Quad/Dual up to 1.8 GHz • Onboard LPDDR4 2 GB / 4 GB, 4000MT/s memory • 2 isolated RS-232/422/485, 2 USB 3.0, 2 GbE LAN, 1 Micro SD, 1 HDMI (1920x1080 at 60Hz) • Support 1 M.2 2242 B-key Slot for 5G/4G/LTE, 1 M.2 2230 E-Key Slot for Wifi • Operation Temperature -20°C to 70°C
Introduction
MXA-200 is an i.MX8M Plus based high-performance IoT gateway, which has an open platform design with Quad Core processor, two RS-232/422/485 isolated serial ports, two 10/100/1000 Ethernet ports, two USB 3.0 port and operating temperature range of -20 to 70°C. It offers two M.2 slots for integrating Wi-Fi/4G/5G modules. MXA-200 enables system integrators to develop applications precisely for renewable energy, EV charger, smart city and factories which require massive data collection, cloud based application and video related monitoring solutions.
Ordering Information
• MXA-200/M2G/Debian MXA-200 iMX8MP DDR4L 2GB with Debian
• MXA-200/M4G/Debian MXA-200 iMX8MP DDR4L 4GB with Debian
• MXA-200/M2G/Yocto MXA-200 iMX8MP DDR4L 2GB with Yocto
• MXA-200/M4G/Yocto MXA-200 iMX8MP DDR4L 4GB with Yocto
Accessory
• 31-62187-1000-A0 AC-DC Power adapter 90W
• 91-95347-3010 WiFi Kit for MXA-200
• 91-95347-4010 5G Kit for MXA-200
• 91-95347-1010 4G/LTE Kit for MXA-200
