Embedded System supporting MXM Graphics
Module with 8th/9th Generation
Intel® Core™ i7/i5/i3 in LGA1151 Socket
Compliant with IEC 60601-1 / IEC 60601-1-2
Features
• ADLINK MXM Graphics module support (Type A/B, up to 120W TDP)
• 8th/9th Gen Intel® Core™ i7/i5/i3, Celeron® processor
• Dual SODIMMs for up to 64GB DDR4 non-ECC memory (dependent on CPU)
• 6x DisplayPort (2 from CPU, 4 from MXM)
• 1x M.2 E key supporting 1630 or 2230 for Wi-Fi/Bluetooth module, 1x M.2 B key supporting 2242 or 2280 for SATA storage module 1x M.2 M key supporting 2242 or 2280 for SATA/PCIe x4 storage module
• Reliable Molex type 12V DC-in connector
• 1x Intel® i219-LM and 3x Intel® i210-AT
• 2x PCIe Gen3 x4 expansion slot for Full Height Half Length add on card, each slot is 25W power budget and additiotal Molex 4 pin power cable (12V/1.5A and 5V/2A) support
Software Support
• Win10 IoT Enterprise SAC 64bit
• Ubuntu 20.04
Optional Accessories
• Black plate of GPU card: 32-50032-1000-A0
• MXM cooler for P1000/P2000: 32-20797-0200-A0
• MMXM cooler for A1000/A2000: 32-20932-0000-A0
• MXM cooler for A4500: 32-20965-0000-A0
• MXM cooler for RTX3000: 32-20823-1100-A0
• 12V/220W Medical grade adapter: 31-62185-0000-A0 (supports GPU up to 60W TDP)
• 12V/300W Medical grade adapter: 31-62188-0000-A0 (supports GPU cards up to 120W TDP)
• Wall Mount Bracket 34-34546-0100-A0 2pcs
• Wifi Kit INTEL AC9260 Non-VPRO 91-95266-0020
